Product Specifications
| Model | B3G |
| Capacity | 5000 Kg |
| Features | Hermetically Sealed |
| Material | Stainless Steel |
| Application | Compressive Testing |
| Cable Length | 6 m |
| Zero balance | +/- 1% FS |
| Accuracy Class | OIML R60 C3 |
| Combined Error | +/- 0.020 % FS |
| Input Resistance | 430 +/- 50 Ohm |
| Output Resistance | 351 +/- 2 Ohm |
| Ingress Protection | IP67 |
| Maximum Safe Overload | 150% FS |
| Output Sensitivity(FS) | 3.0 +/- 0.08 mV/V |
| Ultimate Safe Overload | 300% FS |
| Creep Error (30 minutes) | +/- 0.016 % FS |
| Load Cell Certifications | OIML |
| Maximum Excitation Voltage | 18V DC |
| Operating Temperatue Range | -35 to +65 Deg C |
| Temperature Effect on Zero | +/- 0.015 % FS/DegC |
| Temperature Effect on Output | +/- 0.011 % FS/DegC |
| Compensated Temperature Range | -10 to +40 Deg C |
| Recommended Excitation Voltage | 5 to 12V DC |
| Insulation resistance at 50V DC | >= 5000 M Ohm |
Product Description
Zemic B3G S Type Load Cell, 5000 Kg capacity. Stainless steel construction, IP67 rated. Features hermetic sealing for compressive testing applications. OIML R60 C3 certified.
