Product Specifications
| Mast Rake | +-4 / 5 / 15 Deg Side / forward/backwards |
| Engine Model | CUMMINS QSM11-C400 |
| Gradeability | 35% |
| Rotary Speed | 6 - 22 r/min |
| Max. Line Speed | 60 m/min (Main Winch), 65 m/min (Auxillary Winch) |
| Ground Clearance | 445 mm |
| Operating Weight | 88/89 Ton |
| Track Shoe Width | 800 mm |
| Model Name/Number | XR280D |
| Engine Rated Power | 298 kW |
| Max. Output Torque | 280 kN-m |
| Max. Pulling Force | 260 kN (Main Winch), 80 kN (Auxillary Winch) |
| Max. Drilling Depth | 73/58 m |
| Max. Travelling Speed | 1.5 km/h |
| Max. Drilling Diameter | 2500 mm |
| Distance Between Tracks | 3500 - 4800 mm |
| Max. Pull-down Piston Pull | 220 kN (Crowd Cylinder), 300 kN (Crowd Winch) |
| Max. Pull-down Piston Push | 210 kN (Crowd Cylinder), 300 kN (Crowd Winch) |
| Working Condition Dimension | 10770 x 4800 x 23550 mm |
| Max. Pull-down Piston Stroke | 6 m (Crowd Cylinder), 16 m (Crowd Winch) |
| Hydraulic System Working Pressure | 35 MPa |
| Transportation Condition Dimension | 17410 x 3500 x 3520 mm |
Product Description
Features CUMMINS QSM11-C400 engine (298 kW) and 280 kN-m max output torque. Capable of 73/58 m max drilling depth and 2500 mm max drilling diameter. 88/89 Ton operating weight.
