Product Specifications
| Film Width | Upto 325 mm (Subject to confirmation). |
| Net Weight | 650kg (approx). |
| Peak Power | 5 kW. |
| Pouch Style | 4-Side seal type |
| Pouch Width | 150 mm |
| Feeding head | Variable drive mono block centrifugal pump. |
| Pouch Length | Up to 240 mm. |
| Film Material | Co - Extruded LD multi films. |
| Packing range | Upto 1000 ml. |
| Pouch Counter | Provided |
| Film Thickness | 80 - 100 Microns. |
| Production Speed | 15-30 pouches/minute (Depend Up on Packing Range) |
| Power Consumption | 3.5 kW / Hour. |
| Power requirement | Single Phase/three phase |
| Machine Dimensions in | 2100(H) x 900(W) x 1000(Depth)(mm) |
| Sealer heating system | Impulse Only. |
| Machine control system | Electronic Timers |
| Cooling Water requirement | 100 lit/hr. |
| Outer Dia of the Film Roll | Upto 350mm. |
| Inner Core Dia of Film Roll | 70mm. |
Product Description
This machine handles 80-100 micron films up to 325mm wide, packing up to 1000ml. Features 4-side seal, impulse sealing, and electronic timers. Operates on single/three phase power.
